Intel® 11th Gen CoreTM Processor ( Tiger Lake UP3),Intel Core i5-1135G7, Quad Core Processor, 4 Core/8 Threads, 8M Cache, 0.9-4.2GHz, 28W, New Intel® Xe Graphic (Core i7/ i5 only),Dual Channel DDR4, 2 x SO-DIMMs 3200MHz, Max. 64GB,4 x HDMI port, supporting a maximum resolution 4K/60P,1 x Thunderbolt 4 Port,Intel® AX201 Wifi 6 + BT5.1,Intel® 2.5G + Gigabit Ethernet (225V+219V),ALC255 Audio Codec,2 x M.2 for SSD (1 x PCIe Gen 4 x4 + 1 x PCIe x4/SATA Mode),Infineon TPM onboard*,4 x USB 3.2 (Front), 2 x USB 3.2 (Back),Headphone/microphone jack,Support VESA Mount
Audio
Chipset | Realtek |
Model | ALC255 |
Sunet | HD Audio |
Back Panel
HDMI | 4 |
Retea Ethernet (RJ-45) | 2 |
Thunderbolt | 1x Thunderbolt 4/USB4.0 |
USB 3.1 | 2 |
Carcasa
Culoare | Negru |
Dimensiune | 196.2 x 44.4 x 140 mm |
Suport | VESA 100x100 mm VESA 75 x 75 mm |
Sursa | 135 W sursa externa |
Tip Carcasa | Smal Form Factor |
Conectivitate
Bluetooth | 5.2 |
LAN | 10/100/1000/2500 Mbps |
Wireless | 802.11ax |
Front Panel
Casti | 1x Combo |
USB 3.0 | 4 |
Memorie
Compatibilitate DIMM | SO-DIMM |
Compatibilitate RAM | non-ECC |
Frecventa memorie | 3200 MHz |
Memorie inclusa | Nu |
Memorie maxima | 64 GB |
Sloturi memorie | 2 |
Tip memorie | DDR4 |
Tip RAM | non-ECC |
Tip sloturi memorie | SO-DIMM |
Monitor
Monitor inclus | Nu |
Placa De Baza
SATA III | 1 |
Slot M.2 | Da |
Procesor
Cache | 8 MB Intel Smart Cache |
Familie procesor | Intel Core i5 din a unsprezecea generatie |
Frecventa procesor | 2.40 GHz |
Frecventa turbo max | 4.20 GHz |
Max TDP | 28 W |
Model Procesor | 1135G7 |
Nucleu | Tiger Lake |
Numar nuclee | 4 |
Numar procesoare | 1 |
Numar thread-uri | 8 |
Procesor Grafic integrat | Intel Iris Xe Graphics |
Producator procesor | Intel |
Socket procesor | 1449 |
Tehnologie | 10 nm SuperFin |
Recomandat
Recomandat | Small Office |
Software
Sistem de operare | No OS |
Stocare
Slot M.2 | 2 |
Stocare inclusa | Nu |
Unitate optica
Unitate optica | Nu are unitate optica integrata |
Video
Familie placa video | Iris |
Model placa video | Xe |
Producator placa video | Intel |
Suport DirectX | 12 |
Tip | Integrata |
